ELECTRICAL BED: ATRIA ET1

Electrical hospital bed is a type of bed used in healthcare facilities, particularly in hospitals, nursing homes, and other medical institutions. It is designed to provide comfort and convenience to patients and caregivers, offering various features that can be adjusted electronically. Electrical beds are equipped with motors and controls that allow for easy adjustment of the bed’s position, height, and other functionalities, catering to the specific needs of patients and facilitating the work of healthcare professionals.

TECHNICAL INFORMATION

• Mattress platform is four section, three of them adjustable. Covered with integrated plastic Two – ply surface.
•  Airflow capability under the mattress
•  Backrest and knee raise adjustments are electrically.
•  Foot section is adjustable by means of telescopic bracket.
•  Plastofold collapsible siderails with metal chassis inside
•  Strong siderail hinges made of P.P
•  Two-functional positioning wired handset
•  Detachable head and foot boards with metal connection and suitable ergonomic style for easy handling
•  Washable and disinfectable
•  Four swivel metal castors with cross brake
•  Electrostatic powder coating
•  Main power supply 220V – 50 Hz, 24 DC
•  Max. power input 230 watt
•  Electrical current protection Class2
•  Electrical shock position Type B
•  Duty cycle %10
•  Dust proof and water resistant IPX4
•  IV Stand holder positioned at head / foot board
•  Urine bag holder at both sides



DIMENSIONS and BASICINFORMATION



•  Overall, 2290 x 1020 x 590 (mm)
•  Mattress platform 2000 x 900 (mm)
•  Backrest angle 0º – 85º
•  Knee raise angle 0º – 35º
•  Castors 125 (mm) diameter
•  Bed net weight 112 Kg
•  Safe working load capacity 170 Kg
•  Max. load capacity 250 Kg



ACCESSORIES (Optional)

•  IV stand



STANDARDS



•  ISO 9001
•  ISO 13485
•  IEC 60601-1
•  IEC 60601-2-52
•  EN ISO 14971
•  EN ISO 15223-1
• CE
